【性能特点】Features  and  Functions

1. 主机可进行四次平行折页,梭尾可再进行四次平行折页和一次垂直折页。

Four buckle plates can carry out parallel，again four buckle plates. and then one Electrically-controlled knife can carry out paralle folds and cross folds.

2. 配有纸堆高度自动双重控制系统。

Automatic control device of pile height.

3. 输纸采用高性能飞达。

High performance sheet-separating feeder.

4. 送纸系统采用三孔吸风轮。

Feeding system adopts three holes sucked rotor.

5. 螺旋纹、钢质软聚氨脂折棍组合，防滑、耐磨抗锈。比传统直纹抓纸面积增加75%。

Nonskid,wear proof, anti-rust steel-PU folding roller with screw stripe, so that the contact area is increased by 75% in contacting with the paper.

6. 电气控制采用PLC和变频无极调速并具有变频过载保护功能。

Electric control adopts PLC and variable frequency stepless speed regulation and has variable frequency overload protection function.

7. 灵敏双张、堵塞自动装置系统。稳定可靠、操作方便。可选配人机界面设定。

Sensitive automatic control device of double sheet and jammed  sheet. Man-machine interface facilitates parameter input.

8. 可压痕、打孔和分切。

Indentation, punching, slitting.

9. 皮带传动，低噪，平稳。

Belt driving guarantees smooth driving and low noise.

10. 输纸角度的精密设计能有效的防止纸张起皱。

Designing the angle of the transitional,that`s efficacious in  preventing  the paper wrinkled.

11. 电控到光电合一装置，高速、稳定、可靠、纸张损耗大幅度降低。

Electrically controlled knife of photoelectric integration realizes high speed, superior reliability and minor paper wastage.
